Gateron Quinn Tactile Switches

Sale price$6.10

The switches are sold in packs of 10. Quantity 1 = 10 switches.

Gateron Quinn is a tactile switch by Gateron that has a feel very similar to the Baby Kangaroo switch, but it has a very different sound profile. The same 22mm double staged spring and tactile stem are used, but they incorporate a full nylon housing which greatly changes the sound profile.

Specifications:

  • Manufactured by Gateron
  • Stem: POM
  • Top Housing: Nylon
  • Bottom Housing: Nylon
  • Spring: 22mm double stage gold-plated
  • Operation Force: 59±15g
  • Pre-Travel: 2.0±0.5mm
  • Total Travel: 3.4mm
  • Pins: 5-Pin
  • LED Support: Plug In
  • Pre-lubed: Yes
  • Style: Ahead heavy tactile



Note that these are PCB mount switches. In order to use them in 3-pin hotswap boards (plate mount) you will need to clip the 2 extra plastic pins (very easy to do). Please double check your board and confirm compatibility before buying.
